Smart Big Multiple Dip BMD 45 Thermocouple Tip
V-SMART · SKU v-smart-PUNTA-TERMOPAR-BMD
Temperature sensor for slag-free molten metal, with a Pt/Pt-Rh thermocouple in an extra-long quartz tube and a high-temperature connector that keeps contact after several dips. It allows 8 to 12 measurements depending on the intervals and the metal temperature. Suitable for induction furnaces and ladles.
Technical specifications
| Tube length | 70 mm |
| Thermocouple | Pt/Pt-Rh |
| Contact block | Mini / Mark VII |
| Measuring time | 3 to 12 seconds |
| Number of uses | 8 to 12 dips |
| Nonferrous range | 300 to 1250 °C, type K |
| Maximum immersion | 8 seconds at 1650 °C |
| Ferrous and nonferrous range | 500 to 1750 °C, type S or R |
Specifications subject to confirmation in the formal quote.
